Early diagnosis of traumatic diaphragmatic rupture
Diagnóstico precoz de rotura diafragmática traumática
L. Monge Solaa,
Corresponding author

Corresponding author.
, P.E. Edroso Jarneb, R. Vicho Pereirac
a Servicio de Medicina Intensiva, Hospital Universitario Miguel Servet, Zaragoza, Spain
b Servicio de Medicina Intensiva, Hospital Clínico Universitario Lozano Blesa, Zaragoza, Spain
c Servicio de Medicina Intensiva, Clínica Rotger, Palma, Mallorca, Spain
This item has received
Article information
Full Text
Download PDF
Figures (3)
Show moreShow less
Full Text

An 85-year-old woman was seen in the emergency room with dizziness following a traffic accident. After a few hours she developed breathing difficulties, desaturation and the absence of vesicular murmur upon auscultation. Pulmonary ultrasound evidenced a “C pattern” in the left hemithorax, with peristaltic motion (Fig. 1), and the chest radiographs (Fig. 2) and thoracoabdominal computed tomography scan (Fig. 3) confirmed the diagnosis of diaphragmatic rupture with bowel loop herniation towards the left thoracic space. Emergency surgical repair was carried out and the patient was discharged from intensive care after 5 days. Diaphragmatic rupture often proves fatal – hence the importance of tools allowing early diagnosis and treatment, since they condition the prognosis in such cases.

Figure 1
Figure 2
Figure 3

Thanks are due to the Department of Intensive Care Medicine of Clínica Rotger.

Please cite this article as: Monge Sola L, Edroso Jarne PE, Vicho Pereira R. Diagnóstico precoz de rotura diafragmática traumática. Med Intensiva. 2021;45:510–511.
