Giant ventricular pseudoaneurysm after acute myocardial infarction
Pseudoaneurisma ventricular gigante tras infarto agudo de miocardio
Visits
31
Javier Ceña Carazo
, Marlene Feo González, Adolfo Iñiguez de Diego
Servicio de Medicina Intensiva, Hospital San Pedro, Logroño, Spain
This item has received
Article information
Full Text
Download PDF
Statistics
Figures (3)
Show moreShow less
Full Text

A 68-year-old male was admitted to the Intensive Care Unit due to an inferoposterolateral acute myocardial infarction (Killip class IV). Emergency coronary angiography revealed severe two-vessel coronary artery disease, subjected to angioplasty with the placement of drug-eluting stents. The patient exhibited moderate ventricular dysfunction, in addition to ischemic hepatitis and the need for renal replacement therapy. Control transthoracic echocardiography demonstrated the presence of a lateral aneurysm (Fig. 1, white arrow). The study was completed 7 days later with cardiac magnetic resonance imaging (Figs. 2 and 3). A giant pseudoaneurysm, measuring 90×60mm, was identified (black arrow), accompanied by severe ventricular dysfunction. A very wide neck was observed (suggestive of aneurysm), but without myocardial visualization in the lesion. Furthermore, the lesion demonstrated rapid expansion over the course of one week, suggestive of a pseudoaneurysm. The reference center confirmed the diagnosis and initiated a pre-transplantation evaluation of the patient.

Figure 1
Figure 2
Figure 3
Financial support

None.
